opHA Architecture
opHA Message Bus
Real-time, fault-tolerant, multi-tenant NMIS at any scale
opHA Message Bus is the next-generation architecture for distributed NMIS. It replaces scheduled syncs with a peer-to-peer message bus, so events, configuration, and health data flow between primaries, pollers, and mirrors in real time. The result is a monitoring platform that can scale from one site to thousands of pollers, isolate every tenant cleanly, and keep running through failures that would take older architectures down.
What You See On Day One
Every peer, every daemon, one screen
The opHA-MB Home view is the operational heartbeat of the platform. From this single screen, an operator can see at a glance which pollers are streaming, which daemons are healthy on every peer, and how many nodes each peer is responsible for. There is no need to log into each server, run a status command, or wait for a scheduled sync to complete. The information is live, refreshed by the message bus itself.
Built For Production
From a lab to a globally distributed network
This is the same screen as the lab view, only the numbers and the geography are larger. Pollers carry 1,500 to 2,000 nodes apiece, mirrors track every change in real time from a different region, and every daemon is visible at a glance. When one of those numbers ticks the wrong way, the operator knows in seconds, not minutes.
The architecture is intentionally flat. Add another region, and you add another poller-mirror pair. The message bus handles the rest.
Distributed Service Monitoring
Up, degraded, down, across every site
opHA Message Bus carries service-level state, not just device-level state. SSL expiry checks, port checks, application stack checks, and any other service NMIS or opCharts is running, all stream into one consolidated view. Operators triage from a single table, click through to the source poller, and resolve faster.
For MSPs, Telcos, and ISPs
Real isolation, real visibility, real flexibility
opHA Message Bus is the architecture FirstWave recommends for any deployment with more than one customer behind it. Tenants are isolated at the data layer, not bolted on with filters, and the message bus is what makes that isolation work without forcing every customer onto the same physical server.
Tenant data stays separate
Each tenant's nodes, events, and configuration are isolated end-to-end. A poller can be dedicated to a single customer, shared with strict isolation, or run in a hybrid model. Operators see one consolidated view; customers only ever see their own.
Per-tenant scale, no per-tenant servers
Add a customer, add their pollers, point them at the message bus. There is no need to spin up a parallel NMIS stack per tenant unless you want one. Most MSPs do not.
Single billing surface, single ops surface
One platform to operate, one platform to bill against. Per-tenant counts roll up into the same management views that operators already use.
Capabilities
What the message bus brings to NMIS
Real-time event streaming
Events flow from pollers to primaries the moment they happen, not on the next scheduled sync. MTTR drops because operators see what is happening as it happens.
Zero event loss with replication
Messages are replicated across peers. A server failure does not lose the events that were in flight, and a recovering peer catches up automatically.
Automated primary failover
When a primary peer fails, redundant peers take over the primary role without operator intervention. Monitoring continues, dashboards keep updating, customers do not see downtime.
Horizontal and vertical scale
Add more pollers to cover new sites, or scale existing pollers vertically to carry more nodes. The message bus adapts to either.
Centralised poller configuration
Push poller configuration changes from the primary, not poller by poller. Onboarding new sites becomes a one-step operation.
Live daemon health
Every NMIS daemon on every peer (opchartsd, opeventsd, opconfigd, nmis9d, omkd, ophad) reports health to opHA-MB Home in real time.
Geographic distribution without bandwidth pain
Pollers monitor their local infrastructure. Only the resulting events and metrics travel over the WAN, not the raw polling traffic.
Mirrors for cross-region resilience
Every poller can be paired with a mirror in another region, giving each tenant a live, ready-to-promote replica without manual replication scripts.
NMIS Ecosystem
Drop it in, leave the rest alone
NMIS Core Platform
The message bus extends NMIS into a fully distributed, highly available architecture. Existing configuration, device models, and monitoring policies work unchanged.
opCharts Consolidated View
Dashboards, maps, and charts reflect data from every poller in real time, no more refresh delays or stale tiles.
opEvents Distributed Correlation
Events arrive at opEvents the instant they are generated, anywhere in the estate. Correlation, deduplication, and escalation work across the entire deployment.
All Commercial Modules
opConfig, opReports, opFlow, and opAddress all benefit from the same distributed fabric, with centralised configuration management from the primary.
Under The Hood
Technical Specifications
- Architecture
- Peer-to-peer message bus with primary, poller, and mirror peer types
- Peer types
- Primary (Main Primary, redundant primaries), Poller, Mirror
- Sync model
- Real-time message streaming, with replication across peers
- Heartbeat
- Continuous, surfaced on opHA-MB Home as "A few seconds ago" under healthy conditions
- Daemons monitored per peer
- opchartsd, opeventsd, opconfigd, nmis9d, omkd, ophad
- Deployment models
- Single-tenant, multi-tenant, or hybrid
- Failover
- Automated primary poller failover with zero event loss
- Scaling
- Horizontal (add pollers and mirrors) and vertical (scale existing peers)
- Configuration
- Centralised poller configuration management from the primary
- Geographic distribution
- Pollers and mirrors can be deployed in any region
Ready to run NMIS at message-bus scale?
Talk to our team about how opHA Message Bus can support your distributed, multi-tenant monitoring requirements. We will walk you through the lab view, the production view, and how the architecture fits your deployment.
opHA Message Bus is part of the opHA product family on the NMIS 9 platform.
