We’ve seen it time and time again, a ticket comes into the help desk, a customer is complaining about a slow application or poor voice quality during a call. We start digging into the problem, maybe pull some logs, grab some performance data from the NMS. Everything we find is inconclusive, and when we check back with the client the symptoms have passed. The problem is gone, and another ticket is in the queue, so we move on – no wiser as to what caused the issue – knowing that it will reappear.
The process of getting to the core, or root of a fault or problem is called Root Cause Analysis (RCA). Root Cause Analysis is not a single, stringent process, but rather a collection of steps, often organized specifically by type of problem or industry, which can be customized for a particular problem. When it comes to identifying the root cause of an IT-related event a combination of process-based and failure-based analysis can be employed. By applying an RCA process, and remediating issues to prevent their future occurrence, reactive engineering teams can be transformed into proactive ones that solve problems before they occur or escalate.
In this article I will attempt to outline a general process for troubleshooting network-related events, meaning those issues which directly impact the performance of a computer network or application resulting in a negative impact on user experience. While I will use Opmantek’s Solutions in the examples, these steps can be applied to any collection of NMS tools.
Introduction to Root Cause Analysis
Describing the RCA process is like peeling back an onion. Every step of the process is itself comprised of several steps. The three main steps of the RCA process are included below. The first two steps are often completed in tandem, either by an individual or by a team in a post-mortem incident review meeting.
- Correctly and completely identify the event or problem,
- Establish a timeline from normal operation through to the event,
- Separate root causes from causal factors
Identifying the Event or Problem
Completely and accurately identifying the problem or event is perhaps the easiest part of RCA when it comes to networking issues.
That’s right, I said easiest.
It’s easy because all you have to do is ask yourself Why? When you have an answer to the question Why ask yourself why that thing occurred. Keep asking yourself Why until you can’t ask it anymore – usually that’s somewhere from 4-5 times. This process is often referred to as the 5 Whys.
Many engineers advocate utilizing an Ishikawa, or fishbone diagram to help organize the answers you collect to the 5 Whys. I like this myself, and often utilize a whiteboard and sticky notes while working the problem. If you prefer using a software diagramming tool that’s fine, just use what is comfortable for you.
Example – The Power of Why
Here’s a real-world example Opmantek’s Professional Services team encountered while conducting onsite training in system operation. An internal user called into the client’s help desk and reported poor audio quality during a GoToMeeting with a potential customer.
- Why? – A user reported poor voice quality during a GoToMeeting (first why)
- Why? – Router interface that services switch to user’s desktop experiencing high ifOutUtil (second why)
- Why? – Server backups running during business hours (third why)
- Why? – cron job running backup scripts set to run at 9 pm local timezone (fourth why)
- Why? – Server running cron job is configured in UTC (fifth why)
The team started with the initial problem as reported and asked themselves Why is this happening. From there, they quickly came up with several spot checks and pulled performance data from the switch the user’s desktop was connected to, and the upstream router for that switch; this identified a bandwidth bottleneck at the router and gave us our second Why.
Once the bandwidth bottleneck was identified, the engineers used opFlow, Opmantek’s Netflow/IPFix analyzer to identify where the traffic through the router interface was originating from. This gave them the backup server, and a quick check of running tasks identified the backup job – and there the third Why was identified.
System backups were handled by a cron job, which was scheduled for 9 pm. A comment in the cron job suggested this was meant to be 9 pm local timezone (EST) to the server’s physical location. This gave the team the fourth Why.
A check of the server’s date and time indicated the server was configured for UTC, which gave us the fifth Why.
Not every problem analysis will be this simple, or straightforward. By organizing your Why questions, and their answers, into a fishbone diagram you will identify causes (and causal factors) leading to a problem definition and root cause. In short, keep asking Why until you can’t ask it any further – this is usually where your problem starts.
Establish a Timeline
When establishing a timeline it’s important to investigate both the micro (this event’s occurrence) and the macro (has this event occurred in the past). Thinking back to grade school mathematics, I draw a timeline, a horizontal line, across my whiteboard. In the center I place a dot – this is T0 (time zero) when the event occurred.
To the right of T0 I add tick marks for when additional details were discovered, when the user reported the issue, and when we collected performance or NetFlow information. I also add in marks for when other symptoms occurred or were reported, and for any additional NMS raised events.
To the left of the T0, I place everything we learned from asking Why – when did the backups start, when should they have started? I also review my NMS for events leading up to the performance issue; was interface utilization slowly on the rise, or did it jump dramatically?
Once I have mapped the micro timeline for this one occurrence I begin to look back through my data. This is where having a good depth of time-related performance information comes in handy. Opmantek’s Network Management Information System (NMIS) can store detailed polling data indefinitely which allows fast visual analysis for time-based recurring events.
Example – The Power of Time
As the engineers worked through their Why questions and built a fishbone diagram, they also created a timeline of the event.
They started defining T0 as when the event was reported, but as they collected data adjusted this to when the impact on the network actually started.
To the right of T0, they added in when the user reported the problem, when they started the event analysis, when performance data was collected from the switch and router, and the NetFlow information from the NetFlow collector. They also add in marks when other users reported performance impacts, and when NMIS raised events for rising ifOutUtil on both the router and backup server interfaces.
To the left of T0, they added when the backups started as well as when they should have started. They reviewed NMIS and found the initial minor, major, and warning events for rising ifIOutUtil on the router interface.
Once the timeline was complete the engineering team went on to look for past occurrences of this event. By widening the scale on the router’s interface graphs the engineers could instantly see this interface had been reporting high ifOutUtil at the same time every weekday for several weeks. This cyclic behavior suggested it was a timed process and not a one-time user related event.
Root Causes vs. Causal Factors
As you build out and answer your Why questions you will inevitably discover several possible endpoints, each a potential root cause. However, some of these issues will simply be an issue caused by the root cause – a causal factor – and not the root cause itself.
It is critical to effecting long-term improvements in network performance that these causal factors be identified for what they are, and not misrepresented as the root cause.
Example – Distracted by a Causal Factor
The engineering team quickly realized that all servers had, at one time on the past, been configured for local timezones and had only recently been standardized to UTC. While a process had been in place to identify schedules, like this cron job, and update them for the change to UTC, this one had been missed.
Some members of the team wanted to stop here and fix the cron schedule. However, the wider group asked: Why was a cron job for a critical process, on a critical server, missed in the update process?
Pulling the list of processes and files from the update team’s records showed this file HAD been identified and updated, testing had been completed and verified. This brought about the next question: Why was the updated cron job changed, by who/what process?
While you can address causal factors they are often just a temporary fix or workaround for the larger issue. Sometimes this is all that can be done at the time, but if you don’t identify and completely address the root cause any temporary solutions you apply to causal factors will break down over time.
Example – Finding the Root Cause
Upon digging further, the engineers discovered that the cron job had been properly updated, but an older archived version of the cron job had been copied onto the server via a DevOps process. A Tiger Team was put together to research the DevOps archive and determine the extent of the problem. The Tiger Team reported back to the engineering group the next day; other outdated schedule files were found and also corrected. The engineering team worked with the DevOps engineers to put a process in place to keep the DevOps file archive updated.
Closing Out the Event
At this point, you’ve completed the Root Cause Analysis and identified the core issue causing the reported performance degradation. Since you’ve addressed the root cause this issue should not reoccur again. However, you can’t stop here – there are two follow-up steps that are critical to your future success as an engineering organization –
- Document the issue
I like to use a centralized wiki, like Atlassian’s Confluence, to capture my organization’s knowledge in a central repository available for the entire engineering team. Here I will document the entire event, what was reported by the user, the performance information we captured, the RCA process and the end result – how and what we did to prevent this from happening again. Using tools like Opmantek’s opEvents, I can then relate this wiki entry to the server, router, interfaces, and ifOutUtil event so if it reoccurs future engineers will have this reference available to them.
The root cause has been identified, a remediated put in place, and a process developed to preclude it from happening again. However, this doesn’t mean we’re done with the troubleshooting. There are times where what we assume is the root cause is, in fact, just a causal factor. If that is the case, this problem will reassert itself again as the solution would only be a workaround for the true problem. The solution is to put a process in place, usually through a working group or engineering team meeting, to discuss user impacting events and determine if they relate to either open or remediated RCA processes.
What I’ve presented here is a simplified root cause analysis process. There are additional steps that can be taken depending on the type of equipment or process involved, but if you start here you can always grow the process as your team absorbs the process and methodology.
